• Modern technologies are now an indispensable part of our daily life. Why shouldn't this apply to your windows as well?
• Whether you are looking for unusual designs, sustainable products or smart solutions – REHAU offers you all kinds of possibilities.
• Sliding System Types
• Simple Sliding Systems
• Hebeschiebe Systems
• Automatic Hebeschiebe Systems
• Semi-Automatic Volkswagen Sliding Systems
• Fully Automatic Volkswagen Sliding Systems

HEBESCHIEBE SLIDING SYSTEMS

• The thickness of the case is 190 mm, therefore, a wall thickness of at least 20 cm is required in the application area.
• The carrying capacity for one wing is 300 kg, and wing can be made up to 3000 mm horizontally and 2765 mm vertically.
• Thanks to the specially designed carrier car, it works extremely quietly and easily, and the wing can be fixed at the desired point.
• It can be applied in areas up to 12000 mm wide in a 4-wing system.
• By adding the automation system developed for this system, it turns into a fully automatic remote-controlled and obstacle-recognized sliding system.

AUTOMATIC HEBESCHIEBE SLIDING SYSTEMS

• The thickness of the case is 190 mm, therefore, a wall thickness of at least 20 cm is required in the application area.
• The carrying capacity for one wing is 300 kg, and wing can be made up to 3000 mm horizontally and 2765 mm vertically.
• Thanks to the specially designed carrier car, it works extremely quietly and easily, and the wing can be fixed at the desired point.
• It can be applied in areas up to 12000 mm wide in a 4-wing system.

SEMI-AUTOMATIC VOLKSWAGEN SLIDING SYSTEMS

• It can be applied in Euro 60 – Euro 70 – Euro 86 – Geneo series.
• It is the most secure and highly insulated system among the sliding systems.
• In this system, the wing can be made in the dimensions of 640 mm - 1600 mm horizontally, 700 mm - 2400 mm vertically.
• Its carrying capacity is 130 kg.
• It can be applied up to 1500 mm horizontally and 2400 mm vertically.

FULLY AUTOMATIC VOLKSWAGEN SLIDING SYSTEMS

• It can be applied in Euro 60 – Euro 70 – Euro 86 – Geneo series.
• In the first movement of the window handle, the sash switches to ventilation in the form of a transom, with the second movement it opens completely and leaves the frame.
• This system is called fully automatic because it is opened and closed only with the window handle.
• Intervention to the wing while the arm is in motion causes the system to be locked.
• In this system, the wing can be made in the dimensions of 720 mm - 1850 mm horizontally, 820 mm - 2400 mm vertically.

SIMPLE SLIDING SYSTEMS

• They are systems that are applied only with sliding profiles.
• The two wings move on the rail parallel to each other.
• However, in this system, it is a weak system in terms of insulation, since the insulation is provided only with bristle wicks.
• It can be applied up to 1500 mm horizontally and 2400 mm vertically.
